Your Price: $19.88 / EA
Burndy H-STYLE TIN PLATD COPPER
Add to List
If you would like to purchase a large amount and would like a custom quote, you can add build a quote
Ask about this product H-STYLE TIN PLATD COPPER
Specification Sheet
Detailed Description
Copper Compression H Tap, 6-10 AWG (Main), 6-14 AWG (Tap), Tin Plated.
| Voltage - Maximum: | 35000 |
| Rating - KVA: | 35 kV |
| Product Name: | YH6C6C, Copper Compression H-Tap, Run: #6-10 AWG, Tap: #6-14 AWG, Tin Plated |
| Dimension - Height inch: | 0.81 in |
| Dimension - Strip Length inch: | 3/4 |
| Application: | Wire Tap |
| Finish: | Tin-Plated |
| Material: | COPPER |
| Standard: | UL 486A-486B |
| Temperature Rating: | 194 |
| Type: | Compression Taps |
| Voltage Rating: | 35 kV |
| Special Features: | Features: Accommodates A Wide Range Of Run/Tap Copper Cable Combinations Including Both Flexible And Code Combinations, All (B/B, B/I, I/B, I/I) Combinations Acceptable: Each Connector Has Many Copper Cable Combination Applications Allowing Maximum Flexib |
