Panduit ZnCrd,Cat6A,FTP-S,LSZH,Jk-Plg,WH,5M,RL
Panduit #:SAJLWH5MBL
SKU: PANDSAJLWH5MBL
UPC: 074983116461
SKU: PANDSAJLWH5MBL
UPC: 074983116461
Your Price: $0.00
Panduit ZnCrd,Cat6A,FTP-S,LSZH,Jk-Plg,WH,5M,RL
Add to List
If you would like to purchase a large amount and would like a custom quote, you can add build a quote
Ask about this product ZnCrd,Cat6A,FTP-S,LSZH,Jk-Plg,WH,5M,RL
Specification Sheet
Detailed Description
Category 6A, solid, LSZH, white cable with a Mini-Com TX6 PLUS Shielded Jack Module to TX6 PLUS Shielded Modular Plug.
| Conductor Material: | Copper |
| Color: | White |
| Performance Level*: | Category 6A |
| Boot Type: | Modular Plug |
| Cable Type*: | U/UTP |
| Temperature Rating: | 140 F |
| Length: | 16.40 In. |
| Outside Diameter: | 0.29 In. |
| Wire Size: | 23 |
| Plug Type: | Jack Module- Black |
| Application: | Zone cabling products are designed to provide an efficient and cost effective way to design and deploy cabling systems in data centers and open office architecture environments. |
| Standard: | Exceeds all ANSI/TIA-568-C.2 Category 6A and ISO 11801 Class EA, meets ANSI/TIA-1096-A, meets IEC 60603-7; IEC 60754-1, meets IEEE 802.3af and IEEE 802.3at for PoE applications, UL 1863, CSA Standard C22.2, RoHS Compliant |
| Type: | Shielded Cable Assembly |
