Appleton Electric PG Metric Thread Straight Liquidtight Connector, Size: 1/2 IN, Connection: PG16 Threaded X Compression, Material: Steel, Finish: Zinc Electroplate, In...
Appleton Electric #:PG50-STB
SKU: APPLPG50-STB
UPC: 781381304443
SKU: APPLPG50-STB
UPC: 781381304443
Your Price: $10.84 / EA
Appleton Electric PG Metric Thread Straight Liquidtight Connector, Size: 1/2 IN, Connection: PG16 Threaded X Compression, Material: Steel, Finish: Zinc Electroplate, In...
Add to List
If you would like to purchase a large amount and would like a custom quote, you can add build a quote
Ask about this product 1/2 IN LFMC CONN PG THD
Specification Sheet
Warranty
Detailed Description
PG Metric Thread Straight Liquidtight Connector, Size: 1/2 IN, Connection: PG16 Threaded X Compression, Material: Steel, Finish: Zinc Electroplate, Insulation: Blue Nylon Insulator, Dimensions: 1.44 IN Length X 1-1/4 IN Height, Thread Length: 0.63 IN, Standard: UL 514B, E14814, CSA C22.2 No. 18.3, 65178, German Industry Standard DIN 40430, For Liquidtight Flexible Metal Conduit
| Size: | 1/2 in |
| Finish: | Zinc Electroplate |
| Material: | Steel |
| Application: | For Liquidtight Flexible Metal Conduit |
| Special Features: | Unique long ferrule with more pronounced threads provides over four times UL pull-out requirements; Ferrule also provides maximum surface contact for better sealing and a continuous, permanent, positive metal-to-metal ground; Insulated throat protects aga |
| Standard: | UL 514B, E14814, CSA C22.2 No. 18.3, 65178, German Industry Standard DIN 40430 |
| Type: | PG Metric Thread Straight Liquidtight Connector |
| Connection: | PG16 Threaded X Compression |
| Insulation: | Blue Nylon Insulator |
