Thomas & Betts Insulated Alum Splice
Thomas & Betts #:U 1 N 108
SKU: ABBIU 1 N 108
UPC: 075114100274
SKU: ABBIU 1 N 108
UPC: 075114100274
Your Price: $3.28 / EA
Thomas & Betts Insulated Alum Splice
Add to List
If you would like to purchase a large amount and would like a custom quote, you can add build a quote
Ask about this product
Detailed Description
Insulated Aluminum Service Entrance Compression Splices - Conductor A: Yellow, 1/0 ACSR, 1/0 Stranded, Conductor B: Green, 8 Stranded, 6 Solid. For AL to AL or AL to CU Conductors. Splice only 2-1/8 inch x 37/64 inch Diameter. Splice with Sleeve and Caps 3-1/4 inch x 47/64 inch Diameter. Oil Stop. Installing Dies: CSA-22, 5/8, TU, BG.
| Material: | Aluminum |
| Connection: | Compression |
| Number Of Conductors: | 2 |
| Standard: | ANSI C119.4 |
| Insulation: | Yes |
| Type: | Compression Splice Service Entrance Insulated |
| Color: | Yellow/Green |
| Size: | 3-1/4 inches long |
| Special Features: | Solid center barriers and large chamfers for Easy cable installation. Pre-filled with oxide inhibitor to prevent oxidation and keep out moisture. Constructed from Aluminum for high conductivity. All splices are marked with installation die codes and co |
| Application: | For Standard Conductors |
| Conductor Range: | Side A: #1 SOL , 1/0 STR , 1/0(6/1) ACSR Side B: #6 SOL , #8 STR |
