Burndy HYRDC 2F- 8F STD CLR
Burndy #:YSR2CFX8CFXLTCKITC
SKU: BURNYSR2CFX8CFXLTCKITC
UPC: 781810473948
SKU: BURNYSR2CFX8CFXLTCKITC
UPC: 781810473948
Your Price: $39.45 / EA
Burndy HYRDC 2F- 8F STD CLR
Add to List
If you would like to purchase a large amount and would like a custom quote, you can add build a quote
Ask about this product HYRDC 2F- 8F STD CLR
Specification Sheet
Detailed Description
CU Splice Reducer, Barrel A 2 Flex G,H,I,K,M,DLO, 2 AWG, Barrel B 8 Flex G,H,I,K,M,DLO, 8 AWG, Standard Barrel, Internal Chamfer, Tin Plated, Connector is UL/CSA, 90C Up to 35kV, Kit comes with Clear Heat Shrink, Brown/Red Color Code, 10/49 Die Index.
| Product Type: | SPLICE REDUCER |
| Voltage - Maximum: | 35000 |
| Rating - KVA: | 35 kV |
| Minimum Pack Quantity: | 1 |
| Dimension - Strip Length inch: | 0.78 in |
| Finish: | Tin-Plated |
| Material: | COPPER |
| Application: | Wire Reducing Splice |
| Special Features: | The YSR-TC reducing splice kits provides for two different cable sizes with inspection holes. Barrel is designed with a taper to accomadates a main Run wire that is reduced to a smaller tap wire |
| Type: | YSR-TC |
| Voltage Rating: | 35 kV |
| Conductor Size: | 2 AWG-8 AWG |
