Pass & Seymour HEAVY DUTY DUP RECEPT 15A/125VAC BK
Pass & Seymour #:PS5262BK
SKU: LEGRPS5262BK
UPC: 785007859898
SKU: LEGRPS5262BK
UPC: 785007859898
Your Price: $4.69 / EA
Pass & Seymour HEAVY DUTY DUP RECEPT 15A/125VAC BK
Add to List
If you would like to purchase a large amount and would like a custom quote, you can add build a quote
Ask about this product HEAVY DUTY DUP RECEPT 15A/125VAC BK
Specification Sheet
Warranty
Detailed Description
Heavy-Duty Spec Grade Duplex Receptacle Back and Side Wire 15A 125V
| Color: | Black |
| Indoor/Outdoor: | Indoor |
| Number of Receptacles: | 2.0 |
| Voltage: | 125.0 V |
| Application Sector: | Commercial |
| Amperage: | 15.0 A |
| Country code for ECCN: | MX |
| Outlet Type: | Commercial, Indoor |
| Product Height: | 2.635 in |
| Product Width: | 1.322 in |
| Size: | 1.322 L x .780 W x 3.281 H In |
| Product Depth: | 0.78 in |
| Voltage Rating: | 125 |
| Number of Wires: | 3 |
| Application: | Commercial |
| Material: | Nylon |
| NEMA Rating: | 5-15R |
| Amperage Rating: | 15 |
| Type: | Outlet |
| Mounting: | Wall |
| Number of Poles: | Double Pole |
| Wire Size: | 14 - 10 AWG |
| Connection: | Back and side wire |
| Dielectric Strength: | Withstands 2000V minimum |
| Environmental Conditions: | Flammability: UL94 V2 |
| Standard: | CULUS, FEDSPEC, cULus UL498, CSA C22.2 No. 42 |
| Special Features: | Heavy-duty, brass strap for added strength and ground conductivity. .032 inch thick, brass, triple-wipe power contacts for lasting retention. Strap tabs wrap around face to prevent strap from separating from face and back body. Easily accessed break-off, |
