Mersen Fuse A4J - Class J - Fast-Acting 600VAC 300VDC 600A Blade EI Indicator
Mersen #:A4J600EI
SKU: MERSA4J600EI
UPC: 782001224639
SKU: MERSA4J600EI
UPC: 782001224639
Your Price: $455.04 / EA
Mersen Fuse A4J - Class J - Fast-Acting 600VAC 300VDC 600A Blade EI Indicator
Add to List
If you would like to purchase a large amount and would like a custom quote, you can add build a quote
Ask about this product Fuse A4J - Class J - Fast-Acting 600VAC
Specification Sheet
Detailed Description
Fuse A4J - Class J - Fast-Acting 600VAC 300VDC 600A Blade EI Indicator Amp-Trap
| AC Voltage Rating: | 600 V |
| Body Material: | GMG |
| Connection Material: | Brass Alloy |
| DC Voltage Rating: | 300 V |
| Mounting: | Clip |
| Connection: | Blade |
| Amperage Rating: | 600 A |
| Voltage Rating: | 600 VAC |
| Application: | Capacitors Load centers Panelboards Switchboards Bus duct Feeder circuits Circuit breakers Lighting, heating, and general loads |
| Class: | Class J |
| Interrupt Rating: | 200 kA |
| Special Features: | High current limitation for low peak let-thru current Unique dimensions prevent replacement by other fuse classes Fiberglass body provides dimensional stability in harsh industrial environments Easy-to-read imprint label for quick recognition and replacem |
| Standard: | UL listed to standard 248-8 File E2137 CSA certified to standard C22.2 no. 248.8 DC listed to UL 248 IEC 269-2-1 |
| Type: | Class J |
| Type Of Indicators: | EI Indicator |
| Size: | 8 x 2.5 in |
