Panduit CuCbl,Cat6A,AdvMTX,4Pa,23AWG,WH,1Kft,EA
Panduit #:PUP6AM04WH-UGA
SKU: PANDPUP6AM04WH-UGA
UPC: 613056142893
SKU: PANDPUP6AM04WH-UGA
UPC: 613056142893
Your Price: $0.00
Panduit CuCbl,Cat6A,AdvMTX,4Pa,23AWG,WH,1Kft,EA
Add to List
If you would like to purchase a large amount and would like a custom quote, you can add build a quote
Ask about this product CuCbl,Cat6A,AdvMTX,4Pa,23AWG,WH,1Kft,EA
Specification Sheet
Detailed Description
Copper cable, category 6A U/UTP, plenum (CMP), 4-pair, conductors are 23 AWG with FEP insulation, twisted in pairs, separated by an integrated pair divider, surrounded by an advancedmatrix tape and protected by a flame-retardant PVC jacket, white.
| Conductor Material: | Copper |
| Number Of Conductors: | 4 |
| Type: | Copper Cable |
| Voltage Rating: | 80 V |
| Temperature Rating: | 167 F |
| Construction: | U/UTP |
| Outside Diameter: | 0.28 In. |
| Length: | 1000 FT |
| Jacket Material: | Polyvinyl chloride |
| Color: | White |
| Resistance: | Flame Retardant |
| Standard: | Exceeds the requirements of ANSI/TIA-568-C.2 Category 6A and ISO 11801 Class EA standards for supporting 10GBASE-T transmission, NFPA 262, meets IEEE 802.3af and IEEE 802.3at for PoE applications, RoHS Compliant |
| Weight: | 40.9/1000 ft lb |
| Insulation Material: | FEP, PE |
