Panduit Copper Cable, Cat 6A, 23 AWG, U/UTP, LSZH-3, Blue
Panduit #:PUL6AV04BU-EG
SKU: PANDPUL6AV04BU-EG
UPC: 613056437333
SKU: PANDPUL6AV04BU-EG
UPC: 613056437333
Your Price: $906.15
Panduit Copper Cable, Cat 6A, 23 AWG, U/UTP, LSZH-3, Blue
Add to List
If you would like to purchase a large amount and would like a custom quote, you can add build a quote
Ask about this product Copper Cable, Cat 6A, 23 AWG, U/UTP, LSZ
Specification Sheet
Detailed Description
The TX6A Cat 6A U/UTP copper cable is constructed of 23 AWG copper conductors with HDPE insulation. The copper conductors are twisted in pairs and separated by a cross divider. All four pairs are surrounded by a Vari-MaTriX Tape and a flame-retardant HDPE flame-retardant jacket. The blue, LSZH (IEC 60332-3, EuroClass Dca-s2,d2,a1) cable is supplied 305 meters (1,000 feet) to a reel.
| Conductor Material: | Copper |
| Number Of Conductors: | 4 |
| Type: | Copper Cable |
| Insulation Material: | Polyethylene |
| Jacket Material: | High-Density Polyethylene |
| Outside Diameter: | 0.26 In. |
| Voltage Rating: | 80 V |
| Construction: | U/UTP |
| Temperature Rating: | 140 F |
| Standard: | ANSI/TIA 568.2-D, ISO 11801 |
