Appleton Electric Appleton Mercmaster Jr. Fixture Unit Without Guard, Lamp Type: 70 WTT S62 Medium High Pressure sodium, Lamp Wattage: 70 WTT, Voltage Rating: 120 V, Nu...
Appleton Electric #:MUL70-120
SKU: APPLMUL70-120
UPC: 781381463270
SKU: APPLMUL70-120
UPC: 781381463270
Please Call (865) 483-1766 for Pricing
Add to List
If you would like to purchase a large amount and would like a custom quote, you can add build a quote
Ask about this product MERCMASTER JR 70W 120V HPS
Specification Sheet
Warranty
Detailed Description
Appleton Mercmaster Jr. Fixture Unit Without Guard, Lamp Type: 70 WTT S62 Medium High Pressure sodium, Lamp Wattage: 70 WTT, Voltage Rating: 120 V, Number Of Lamps: 1, Material: Copperfree (4/10 Of 1 PCT Maximum) Aluminum Mounting Hood, Ballast Bodies, Fixture Wattage: 82 WTT, Amperage Rating: 0.7 AMP Starting, 0.73 AMP Operating At 120 V, Housing Finish: Epoxy Powder Coat, Housing Material: Copperfree (4/10 Of 1 PCT Maximum) Aluminum, Ambient Temperature Range: 25 DEG C, Temperature Range: 231 - 260 DEG C, Lens Material: Globe, Ballast Type: High Power Factor (HPF), Ballast Quantity: 1, Frequency: 60 HZ, Standard: Class I, Division 2, Groups A, B, C, D, Class II, Division 1 And 2, GroupsE, F, UL Listed: E10444, 1598, 1598A, 844, Inexpensive Hid Integrally Ballasted Fixture For Use In Hazardous Locations - Inexpensive To Buy And Inexpensive To Operate, Enclosed And Gasketed Hid Lighting Fixtures For Use In Tunnels, Walkways, Bridges, Storage Facilities, Processing Plants, Parking Lots, Foundries, Manufacturing Plants, Power Plants And Other Locations Where Moisture, Dirt, Dust Or Corrosive Atmospheres Are Encountered
| Ballast Quantity: | 1 |
| Housing Material: | Copperfree (4/10 Of 1 PCT Maximum) Aluminum |
| Ambient Temperature Range: | 25 DEG C |
| Housing Finish: | Epoxy Powder Coat |
| Lamp Wattage: | 70 WTT |
| Fixture Wattage: | 82 WTT |
| Temperature Range: | 231 - 260 DEG C |
| Lens Material: | Globe |
| Number Of Lamps: | 1 |
| Voltage Rating: | 120 V |
| Lamp Type: | 70 WTT S62 Medium High Pressure Sodium |
| Special Features: | Wireless design; Threading of fixture unit onto mounting hood makes electrical connection; Only wiring required is attaching two wires to connection block in mounting hood; Unitized construction reduces installation and maintenance costs; Ballast has stan |
| Amperage Rating: | 0.7 AMP Starting, 0.73 AMP Operating At 120 V |
| Application: | Inexpensive Hid Integrally Ballasted Fixture For Use In Hazardous Locations - Inexpensive To Buy And Inexpensive To Operate, Enclosed And Gasketed Hid Lighting Fixtures For Use In Tunnels, Walkways, Bridges, Storage Facilities, Processing Plants, Parking |
| Ballast Type: | High Power Factor (HPF) |
| Material: | Copperfree (4/10 Of 1 PCT Maximum) Aluminum Mounting Hood, Ballast Bodies |
| Standard: | Class I, Division 2, Groups A, B, C, D; Class II, Division 1 And 2, Groups E , F; UL Listed: E10444, 1598, 1598A, 844 |
| Type: | Fixture Unit Without Guard |
