Thomas & Betts Al Serventr Comp Splice 1/0 4 Seal
Thomas & Betts #:UYO 04 SP
SKU: ABBIUYO 04 SP
UPC: 783786756025
SKU: ABBIUYO 04 SP
UPC: 783786756025
Your Price: $2.84 / EA
Thomas & Betts Al Serventr Comp Splice 1/0 4 Seal
Add to List
If you would like to purchase a large amount and would like a custom quote, you can add build a quote
Ask about this product
Detailed Description
Aluminum 2-3/4 inch Service Entrance Compression Splice for Wire Range, End A: 1/0 ACSR, 1/0 STR, Orange, End B: 4 ACSR, 3-4 Stranded, 2 Solid, Orange, Die: 5/8, with Seal Plug.
| Material: | Aluminum |
| Number Of Conductors: | 2 |
| Connection: | Compression |
| Standard: | ANSI C119.4 |
| Type: | Service Entrance Compression Splice |
| Special Features: | Solid Center Barriers. Large Chambers. Nylon Sleeves. Oxide Inhibitor. Colored Caps. Seal Plug |
| Application: | For Standard Conductors |
| Size: | 2-3/4 inch long |
| Finish: | Nylon Sleeve |
| Insulation: | yes |
| Wire Size: | Side A: 1/0 ACSR or 1/0 STR AWG , Side B: #4 ACSR or #3 to #4 STR or #2 SOL AWG |
