General Cable 4 AWG TYPE W (UL)-BLUE 17 MISC
General Cable #:80631.99.17
SKU: PRYS80631.99.17
UPC: 079407421718
SKU: PRYS80631.99.17
UPC: 079407421718
Your Price: $0.00
General Cable 4 AWG TYPE W (UL)-BLUE 17 MISC
Add to List
If you would like to purchase a large amount and would like a custom quote, you can add build a quote
Ask about this product 4 AWG TYPE W (UL)-BLUE 17 MISC
Specification Sheet
Detailed Description
Super Vu-Tron SGL Conductor Type W Extra Flex 90C 2000V UL Listed, 4 AWG TYPE W (UL)-Blue 17 MISC
| _Jacket Material: | Super Vu-Tron |
| _Conductor: | 1 |
| _Insulation Material: | Premium-grade 90C EPDM |
| _Jacket Color: | Blue |
| _Standards: | UL Listed MSHA Approved RoHS Compliant CSA Certified |
| _Conductor Stranding: | 416/30 |
| Conductor Size: | 4 |
| Temperature Rating: | 90c |
| Conductor Material: | Fully annealed stranded bare copper |
| Application: | PORT PWR SYSs Entertainment industry activities such as theater, television, night clubs, motion pictures, mobile COMM vans, spotlights and sound SYSs Other similar applications that would require temporary PWR |
| Length: | 12.000000000000000 in |
| Special Features: | Water-RST Sunlight-RST Designed to withstand severe environmental conditions Withstand exposure to oil, acids, alkalines, HT, flame, moisture, and chemicals Meets or exceeds flame test requirements of MSHA |
| Voltage Rating: | 2000 |
| Amperage Rating: | 140 |
| Weight: | 0.4427 L |
