Prysmian Group 3C/20 7/28TC 1000' Pull-Pac BLK
Prysmian Group #:C4118A.30.01
SKU: PRYSC4118A.30.01
UPC: 079407275977
SKU: PRYSC4118A.30.01
UPC: 079407275977
Your Price: $0.00
Prysmian Group 3C/20 7/28TC 1000' Pull-Pac BLK
Add to List
If you would like to purchase a large amount and would like a custom quote, you can add build a quote
Ask about this product 3C/20 7/28TC 1000' Pull-Pac BLK
Specification Sheet
Detailed Description
Multi-Conductor, Unshielded, AWM style 2464, CSA Type AWM I/II A/B, NEC/CEC Type CMG (CSA C/US), 3C/20 7/28TC UNSH TYPE CMG, Black
| Conductor Size: | 20 AWG |
| Jacket Material: | PVC |
| Color: | Gray |
| NEMA Color: | Gray |
| Type: | Communication & Contol Cable, Multi-Conductor |
| Number Of Conductors: | 3 |
| Insulation Material: | Premium-grade, color-coded PVC |
| Strands: | 7/28 |
| Application: | Public address systems, intercoms, internal telephones, remote control circuits, suitable for EIA RS-232 applications, suggested voltage rating; 300 or 600 volts |
| Conductor Material: | fully annealed, stranded tinned copper |
| Special Features: | Easy to terminate, excellent electrical properties, tinned conductors provide excellent corrosion resistance, assists soldering applications |
| Standard: | AWM Style 2464 (CSA: 80C, 300V); CSA Type AWM (105C, 600V); CSA Certified CMG to harmonized standard UL 444 and CSA 22.2 No. 214; NEC/CEC Type CMG (CSA: 105C, 300V); RoHS Compliant Directive 2002/95/EC; Designed to meet CSA 70,000 BTU Vertical Tray Flame |
| Temperature Rating: | (-20C to +105C) |
| Outside Diameter: | 0.216 in |
