Thomas & Betts 15kv Cable Termination Ranger2
Thomas & Betts #:R2IT15J2-N0330-B3
SKU: ABBIR2IT15J2-N0330-B3
UPC: 075114359856
SKU: ABBIR2IT15J2-N0330-B3
UPC: 075114359856
Your Price: $418.14 / EA
Thomas & Betts 15kv Cable Termination Ranger2
Add to List
If you would like to purchase a large amount and would like a custom quote, you can add build a quote
Ask about this product
Specification Sheet
Detailed Description
Ranger2 Termination. Type - Indoor, 15kV, Cable Type - Concentric Neutral/Jacketed Concentric Neutral, Insulation Range - .84 inch - 1.38 inch, Connector Type - Aluminum 2-Hole Spade #2-1250 kcmil, Conductor Code - 330 -Stranded or Compressed 500, Compact or Solid 600. Cable Mounting Bracket - B3 - Stainless Steel - Size 1.45 inch - 1.95 inch.
| Cable Type: | Concentric Neutral Wire |
| Color: | Dark Gray |
| Conductor Size: | 500 to 600 kcmil |
| Earthing: | Products Includes Their Own Grounding System |
| Mounting: | Product Need to have Cable Holder (not included) |
| Number Of Terminals: | (1) Single Phase |
| Special Features: | Silicone Rubber Housing. Lightweight, Compact Design. Pull-Down Tabs for Easy Installation. Thick Wall Construction |
| Standard: | IEEE 48 |
| Voltage Rating: | 15 kV |
| Application: | Cable Termination, Indoor Application, 15kV |
| Type: | Cable Termination - Indoor - Ranger2 |
