Leviton 5376 EB REC SGL SURF MNT 2PO 3WI
$0.00
Leviton #: 5376
SKU: LEVI5376
UPC: 078477235201
SKU: LEVI5376
UPC: 078477235201
| Color: | Black |
| Size: | 4.82 H x 2.68 W x 24 D IN |
| Voltage Rating: | 250 |
| Number of Wires: | 3 |
| Amperage Rating: | 30 AMP |
| Number of Poles: | 2 |
| Application: | Commercial |
| Dielectric Strength: | 2000 (Min.) |
| Environmental Conditions: | Flammability (Rated V-2 per UL94) |
| Temperature Rating: | -40 to +60 DEG C |
| Wire Size: | 14-6 |
| Connection: | Side Wired |
| Material: | Thermoplastic |
| Standard: | NEMA (WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA C22.2 No. 42 (File 152105);UL Listed 498 (File E13399, File E13393) |
| Type: | Power Receptacle |
| NEMA Rating: | 6-30R |
| Mounting: | Surface |
